OI110 – Dual CameraLink

OI110 is a combination of a dual-lane CameraLink camera interface card and the EMC²-DP integrated on a PC/104 form-factor.

The two CameraLink interfaces will offer a dual-vision interface to a range of applications and either controlled by a Host Controller or running as a stand-alone mode. The integrated Xilinx FPGA allows any CameraLink format to connected to OI110. The additional SATA-3 expansions allow connection to large storage for future processing.


 Key points of the I/O module

  • Dual CameraLink Ports
  • Dual Single SATA-3 Ports
  • PoCL (Power over Camera Link) support
  • Up to 85 MHz data rate
  • Dual Base, Single Medium Base
  • Single Extended Full CL Base


Key points of the carrier

  • PCIe/104 OneBank or Type 1 or Type 2 compatible
  • PCI Express Gen 2 compatible and integrate PCI Express switch
  • An infinitive number of IO110’s can be stacked for multiple camera inputs
  • Expandable with any PCIe/104  I/O Module for more flexibility
  • Can be a “Single-Board-Computer” and run stand-alone or part of a system
  • 96mm x 90 mm PC/104 Form-Factor with Cable-less Break-Out PCB Connector


The IO110 needs to be coupled with the FPGA module of your choice.  Depending on the application you are designing for, we have a range of Xilinx Artix, Kintex and Kintex UltraScale FPGAs or Zynq SoC to suit. They are all based on the Trenz 5×4 System on Module standard for ultimate flexibility.
